Magnetic Module, More Efficient Installation
Quick Front/Rear Maintenance
DN-B & DN Plus-B Outdoor Version
Front IP65 Rear IP54
Rain & Dust Proof
Crisp visuals with vibrant detail
Optimized performance with low power
Durable build for long-lasting safety
Seamless control with modern linking
Reduced strain for effortless viewing
Reliable shielding in all conditions
| Model No. | DN/DN Plus2.6 | DN/DN Plus2.9 | DN/DN Plus3.9 | DN/DN Plus3.9 |
| Pixel Pitch | 2.6mm | 2.9mm | 3.9mm | 3.9mm |
| LED Type | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Packaging Technology | SMD | SMD | SMD | SMD |
| Pixel Density | 147456 pixel/㎡ | 112896 pixel/㎡ | 65536 pixel/㎡ | 65536 pixel/㎡ |
| Panel Dimension | DN Plus :500mm*1000mm*76mm DN:500mm*500mm*76mm |
DN Plus :500mm*1000mm*76mm DN:500mm*500mm*76mm |
DN Plus :500mm*1000mm*76mm DN:500mm*500mm*76mm |
DN Plus :500mm*1000mm*76mm DN:500mm*500mm*76mm |
| Panel Resolution | DN Plus :192*384 pixel DN:192*192 pixel |
DN Plus :168*336 pixel DN:168*168 pixel |
DN Plus :128*256 pixel DN:128*128 pixel |
DN Plus :128*256 pixel DN:128*128 pixel |
| Scan Rate | 1/24 or 1/16 | 1/21 or 1/14 | 1/8 | 1/16 |
| Brightness | General Brightness for Black LEDs: 2500-3000nits High Brightness for Black LEDs: 3000-3500nits General Brightness for White LEDs: 3000-3500nits High Brightness for White LEDs: 3500-4000nits |
General Brightness for Black LEDs: 2000-2500nits High Brightness for Black LEDs: 2500-3000nits General Brightness for White LEDs: 3000-3500nits High Brightness for White LEDs: 3500-4000nits |
General Brightness for Black LEDs: 2800-3000nits High Brightness for Black LEDs: 4000-4500nits General Brightness for White LEDs: 4000-4500nits High Brightness for White LEDs: 5000-5500nits |
General Brightness for Black LEDs: 2300-2500nits High Brightness for Black LEDs: 3500-3800nits General Brightness for White LEDs: 3500-4000nits High Brightness for White LEDs: 4500-5000nits |
| Refresh Rate | 3840Hz/7680Hz | |||
| Gray Scale | 14-16Bit | |||
| Color Temperature | 6500-9500K | |||
| Panel Weight | DN: 7.2kg±10% DN Plus: 12.5kg±10% | |||
| Panel Material | Die-Casting Aluminum | |||
| Max. Power Consumption | White LED:≤580w/㎡; Black LED:≤720w/㎡ | |||
| Ave. Power Consumption | White LED:≤290w/㎡; Black LED:≤360w/㎡ | |||
| Viewing Angle | H:160°/V:140° | |||
| Working Voltage | AC200-240V~50/60Hz or AC100-240V~50/60Hz | |||
| IP Rating | Front IP65, Rear IP54 | |||
| Maintenance | Rear | |||
| Curve | Curved cabinet/45° beveled cabinet（±10° curved lock）：-10°/-7.5°/-5°/-2.5°/0°/2.5°/5°/7.5°/10° 90° lock or 90° connector plate can do vertical splicing. |
|||
| Max. Stacking/Hanging Height | 10m | |||
| Operating Temp/Humidity | -20℃~+45℃; 10%~90%RH | |||
| Storage Temp/Humidity | -40℃~+60℃; 10%~60%RH | |||
| Control System | Novastar/Magnimage/Colorlight | |||
| Product Certification | MET/CE/EMC | |||
